JetSprayer

​

Quantity

4

High-Speed Centrifugal Nozzle Quantity

4

Droplet Size

60–200 μm

Spray Width

Max. horizontal range per side: 7 m
Max. spray height: 1.5 m (depending on operating speed, wind speed, environment, etc.)

Gimbal Adjustment Angle

Horizontal rotation: 180°
Vertical tilt: −10°–90°

Control & Perception System
Vehicle Control

​

Vehicle Control System

SuperX 5 Ultra Intelligent Control System

Wide-Angle FPV View

Video Resolution

1920×1080

Power Supply Voltage

24 V

Frame Rate

30 FPS

Video Encoding Format

H.265

Image Sensor

1/2.7-inch CMOS-RGB image sensor; 5 effective megapixels

Focal Length

1.83 mm

Field of View (FOV)

Horizontal: 150°
Vertical: 105°

Powertrain

​

Drivetrain

Independent 6WD; differential steering

Number of Motors

6

Protection Rating

IPX6

Rated Motor Power (Single Motor)

100 W

Tyre Size

16-inch pneumatic tyre

Tyre Inflation Pressure

30 psi

SRC5 Remote Controller

Model

M3SRC5AH

Dimensions

260mm x 140mm x 89mm

Weight

1.2 Kg

Operating System

Android

Battery Capacity

20000mAh (3.65V)

Charging Protocol

Supports QC Charging protocol

Charging Ambient Temperature

5°C to 40°C

Operating Ambient Temperature[8]

-10°C to 40°C

Storage Ambient Temperature

-20°C to 55oC Less than a Month
-20°C to 45°C One to three months
-20°C to 25°C Three months to one year

Charging Voltage / Current

5V⎓3A, 12V⎓2.5A, 15V⎓3.0A

Max Transmission Distance[9]
(Unobstructed, free of interference)

SRRC: 2000 Meters
FCC: 2000 Meters
CE/MIC: 1000 Meters

Voice Prompt

Yes

Screen Brightness

1200 cd/m2

Screen Resolution

1920 x 1200

Screen Size

7.02 inches

Screen Frame Rate

60 fps

Compatible Aircraft

XAG® P150 Max Agricultural Drone

Operating Frequency (Wi-Fi)

2.400 - 2.4835 GHz; 5.725 - 5.850GHz

Effective Isotropic Radiated Power
(Wi-Fi)

2.400 GHz ~ 2.4835 GHz
≤33 dBm (FCC)
≤20 dBm (CE/SRRC/MIC)

5.725 GHz ~ 5.850 GHz
≤33 dBm (FCC)
≤30 dBm (SRRC)
≤13.98 dBm (CE)

Operating Frequency (Bluetooth)

2402 MHz ~ 2480 MHz

Effective Isotropic Radiated Power (Bluetooth)

≤10 dBm

2G Operating Frequency

CE: GSM900: 800 – 915 MHz
925 – 960 MHz
DCS1800: 1710 – 1785 MHz
1805 – 1880 MHz
FCC: GSM850; PCS1900
ANATEL: GSM850, GSM900, GSM1800, GSM1900

2G Max. Transmit Power

Class 1 (30 dBm ±2 dB) for DCS1800
Class 4 (33 dBm ±2 dB) for GSM900

3G Operating Frequency

CE: WCDMA Band 1 1920 – 1980 MHz
2210 – 2170 MHz
WCDMA Band 8 880 – 915 MHz
925 – 960 MHz
FCC: WCDMA B2, WCDMA B4
KCC: WCDMA B1
ANATEL: WCDMA B1, WCDMA B2,
WCDMA B5, WCDMA B8
MIC: WCDMA B1, WCDMA B5,
WCDMA B6, WCDMA B8,
WCDMA B19

3G Max. Transmit Power

Class 3 (24dBm + 1/-3 dB) for WCDMA bands

4G Operating Frequency (LTE)

CE: LTE B1, LTE B3, LTE B7, LTE B8,
LTE B20, LTE B28, LTE B38, LTE B40
FCC: LTE B2, LTE B4, LTE B5, LTE B7,
LTE B25, LTE B26, LTE B38, LTE B41
KCC: LTE B1, LTE B3, LTE B5, LTE B7, LTE B8
ANATEL: LTE B1, LTE B3, LTE B5, LTE B8, LTE B25
LTE B26, LTE B28, LTE B39, LTE B40, LTE B41
MIC: LTE B1, LTE B3, LTE B5, LTE B8, LTE B18
LTE B19, LTE B26, LTE B41

4G Max. Transmit Power

Class 3 (23 dBm ±2 dB) for LTE bands

GNSS Frequency Band

BDS: B1
GPS: L1C
GLONASS: L1
Galileo: E1

Specifications
XAG R200

​

Net Weight

130 kg (with Onboard RevoSpray)

Max. Payload

240 kg (with Onboard RevoSpray and battery)

Wheel Track

705 mm

Wheelbase

950 mm

Min. Ground Clearance

270 mm

Min. Turning Radius

0 m; supports on-the-spot turning

Max. Speed

1.5 m/s

Max. Gradeability

20%

Operating Ambient Temperature

0–40 °C

RevoSpray System

Smart Liquid Tank

Liquid Tank Rated Capacity

240 L

Flexible Impeller Pumps

Quantity

4

Single Pump Flow Rate

2–4 L/min

Max. Flow Rate

16 L/min
